Mean Well LRS-150F-12 150W Single Output Switching Power Supply LRS-150F 12V/12.5A

Description

• Universal AC input / Full range
• Withstand 300VAC surge input for 5 second
• No load power consumption<0.5W
• Miniature size and 1U low profile
• High operating temperature up to 70
• Protections: Short circuit / Overload / Over voltage /Over temperature
• Cooling by free air convection
• Compliance to lEC/BS EN/EN 60335-1(PD3) and IEC/BS EN/EN61558-1,2-16 for household appliances
• Operating altitude up to 5000 meters,Withstand 5G vibration test,High efficiency, long life and high reliability
• LED indicator for power on,Over voltage category IlI,100% full load burn-in test

LRS-150F series is a 150W single-output enclosed type power supply with 30mm of low profile design.Adopting the full range 85~264VAC input, the entire series provides an output voltage line of 5V,12V,15V,24V,36V and 48V. In addition to the high efficiency up to 90%, the design of metallic mesh case enhances the heat dissipationof LRS-150F that the whole series operates from -30 through 70C under air convection without a fan.Delivering an extremely low no load power consumption (less than 0.5W), it allows the end system toeasily meet the worldwide energy requirement.LRS-150F has the complete protection functions and 5G anti-vibration capability; it is complied with the international safety regulations such as TUV BSEN/EN62368-1,BS EN/EN60335-1,BSEN/EN61558-1/-2-16,UL62368-1 and GB4943.LRS-150Fseries serves asa high price-to-performance power supply solution for various industrial applications.
