AIR802 Omni-Directional Antenna, 3500 to 3700 MHz (3.5 to 3.7 GHz), 10 dBi, N Plug-Male

Description

• Excellent Design and Performance
• 3.5 to 3.7 GHz

AIR802 model ANOM3510M is an omni-directional 10 dBi gain antenna for the 3500 to 3700 MHz (3.5 to 3.7 GHz) band. This is a mesh mount style antenna with a N plug or male connector. Our mesh antennas are designed to be directly connected to a wireless access point. Alternatively they may be mounted on a bulkhead connector. This antenna is manufactured in our Aurora, Illinois USA facility.
Applications
Citizens Broadband Radio Service (CBRS)
WiMax
Specifications
Frequency: 3500 to 3700 MHz (3.5 to 3.7 GHz)
Free Space Realized Gain: > 10 dBi
Side Lobe: <-12 dB
VSWR: 1.75
Polarization: Vertical
Vertical Beam Width: 8.6 - 8.7 for both Phi 0 and 90
Horizontal Beam Width: 360
Omni-Directional Pattern Non-Circularity: <0.5 dB
Impedance: 50
Design: PCB
Connector: N Plug-Male
Dimensons: 1.0 x 25.8 inches (25.4 x 657 mm)
