2-Channel Isolated CAN FD Expansion HAT for Raspberry Pi 4B/3B+/3B/2B/Raspberry Pi Zero W WH/Raspberry Pi Zero 2W 2WH/ Jetson Nano, with MCP2518FD CAN Controller Onboard Multi Protection Circuits

Description

• Designed for Raspberry Pi series,Jetson Nano Based on Raspberry Pi design, suitable for Raspberry Pi Zero/Zero W/Zero WH/2B/3B/3B+/4B. And it can also supports Jetson Nano Developer Kit (B01) and Jetson Nano 2GB Developer Kit.
• 2-Channel CAN Support MCP2518FD CAN controller + CAN transceiver chip
• up to 4-CH CAN by cascading Onboard SPI0 / SPI1 chip select and interrupt pin configuration, avoid conflicting with other SPI slave devices, also used for cascading to support 4-ch CAN communication
• Electrical isolation circuitry, safe & stable SM24CANB TVS diode, ESD protection, transient peak voltage protection
• Flexible and handy jumpers Easily select 3.3V / 5V operating voltage, or enable/disable 120 terminal resistor, via onboard jumpers

Overview
The 2-CH CAN FD HAT is a 2-Channel CAN bus expansion HAT designed for Raspberry Pi, supports CAN FD (CAN with Flexible Data-Rate). It will enable CAN bus for your Raspberry Pi, not only the original CAN 2.0 protocol, but also the CAN FD extension, with higher data throughput.
Onboard multi protection circuits, including 500W lightningsurge, ESD protection, short circuit protection, and electrical isolation, which make the communication more safe and more reliable.

Features
Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi series boards (Raspberry Pi Zero/Zero W/Zero WH/2B/3B/3B+/4B ), Jetson Nano.
Support external wide voltage of 8~28V to supply power to Raspberry Pi and 2-CH CAN FD HAT at the same time or directly supply power to 2-CH CAN FD HAT from Raspberry Pi.
Supports both traditional CAN2.0 and CAN FD protocols.
Reserved control interface for easy control by other controllers whose logic voltage is 3.3V/5V.
Onboard electrical isolation, up to 5KV isolated voltage, stable operation, higher anti-interference capability.
Onboard lightningproof, ESD protection, short circuit protection, more safe communication.
Onboard voltage translator, select 3.3V/5V operating voltage by jumper.
Onboard 120 terminal resistor, configured by jumper.
Comes with development resources and manual (examples for Raspberry Pi/Arduino).

Specifications
Power input terminal voltage: DC 8~28V
Logic level: 3.3V/5V
CAN controller: MCP2518FD
Control bus: SPI
Dimensions: 65.0 x 56.5 mm
Fixed hole through diameter: 3.0mm

Online Tutorial/Online Document: n9.cl/v5hdg

Package Content
2-CH CAN FD HAT x1
220PIN female header x1
Standoffs pack (2pcs) x1
