15W 220V AC Gear Electric Motor With Speed Regulator Adjustable Speed Single Phase Asynchronous High 3IK15RGN-C (Size : 0-37RPM)

Description

• Motor Drives

Motor Drives
15W 220V AC Gear Speed Motor With Speed Regulator 3IK15RGN-CAdjustable Speed Single Phase Asynchronous High Deceleration
Model:15W Gear Motor 3IK15RGN-C
Speed ratio: 3k,5K,7.5K,10K,12.5k,15K,20K,25K,30K,40K,
50K,60K,75K,90K,100K,120K,150K,180K,200K
The maximum speed of the motor:1350rpm
output speed
3K(0-450RPM), 5K(0-270RPM), 7.5K(0-180RPM), 10K(0-135RPM),
12.5K(0-108RPM),15K(0-90 RPM),18K(0-75RPM),20K(0-67RPM),
25K(0-54RPM),30K(0-45RPM),36K(0-37RPM),40K(0-33RPM),
50K(0-27RPM),60K(0-22 RPM) 75K(0-18RPM), 90K(0-15RPM),
100K(0-13.5RPM), 120K(0-11RPM)150K(0-9RPM),180K(0-7.5RPM),200K(0-6RPM)
Currently, we configure the default speed regulator you. If you want another speed regulator, we will modify it according to your needs. In addition, the may change slightly.
Speed Controller Dimensions and wiring Diagram
AC Gear Speed Motor*1With Speed Regulator*1
