1.43inch AMOLED Display Development Board ESP32-S3, 466466, QSPI Interface Round Display, Onboard Accelerometer and Gyroscope Sensor, with Metal Case @XYGStudy (ESP32-S3-Touch-AMOLED-1.43-B)

XYGSTUDY

1.43inch AMOLED Display Development Board ESP32-S3, 466466, QSPI Interface Round Display, Onboard Accelerometer and Gyroscope Sensor, with Metal Case @XYGStudy (ESP32-S3-Touch-AMOLED-1.43-B)

662,15 kr. 1 103,58 kr.
Buying Bulk?
  • Order within 9 hours and 34 minutes to get between June 11 - June 17
  • Tracked Shipping on All Orders
  • 14-Day Returns
  • Secure Payments
  • 24/7 Customer Support
Buying Bulk?

Description

  • Part Number: ESP32-S3-Touch-AMOLED-1.43-B
  • ESP32-S3 1.43inch AMOLED Display Development Board, 466466, QSPI Interface Round Display, Onboard Accelerometer And Gyroscope Sensor, RTC Chip, Optional For CNC Metal Case, ESP32 With Display
  • This product adopts ESP32-S3R8 chip with 2.4GHz WiFi and Bluetooth BLE 5 support, integrates high-capacity Flash and PSRAM. Onboard 1.43inch AMOLED display which can smoothly run GUI programs such as LVGL.
  • Onboard rich peripheral resources such as RTC chip, QMI8658 6-axis IMU, TF card slot, Lithium battery header, etc., and reserved USB, UART, I2C and GPIO pin headers, offering strong compatibility and expandability. It is suitable for the quick development of the HMI and other ESP32-S3 applications.
  • Equipped with high-performance Xtensa 32-bit LX7 dual-core processor, up to 240MHz main frequency Supports 2.4GHz Wi-Fi (802.11 b/g/n) and Bluetooth 5 (LE), with an onboard antenna. Supports switching to use external antenna via resoldering an onboard resistor Built-in 512KB SRAM and 384KB ROM, with onboard 16MB Flash and 8MB PSRAM
