Coolgear 10 Port USB Hub - 5Gbps Speed, Surge Protection, DIN Rail Mounting, Industrial Grade for Tech Labs, Warehouses, Automation, Schools & More

Description

• [ Industrial Grade ] : +7-24V DC Input | 15KV Surge Protection | Surface Mountable | DIN-Rail Mountable | 5 Gbps | Screw Lock | 10 USB Type A Ports
• [ Super Fast Speeds ] : This USB hub is 3.1 Gen 1 compliant, ensuring fast 5Gbps data transfer speeds, with backwards compatibility to support USB 2.0 and USB 1.1 speeds.
• [ Protect Your Equipment ] : The 10-port USB 3.0 hub features 15kV per port ESD and 350 Watts of surge protection to keep your connected peripherals safe.
• [ Rugged and Mountable ] : Industrial-grade metal enclosure with built-in wall mounting flanges and DIN-Rail brackets allows for secure, space-saving installations in demanding environments.
• [ Connectivity ] : Upstream: 1 USB Type B Port | Downstream: 10 USB Type A Ports | Power Connector: 2-pin Terminal Block.
• [ Why Coolgear? ] : Your Trusted Partner based in the USA, Providing Advanced Engineering, Highly Reliable and Superior Built Products to handle the most demanding industries for over 20 years. Reach out to us for CAD, Mechanical Drawings and, Data Sheets.

Industrial Grade | +12~24V DC Input | Surge Protection | Surface Mountable | DIN Rail | 5 Gbps | Screw Lock Protect Your Equipment: The 10-port USB 3.2 Gen 1 features 350 Watts of surge protection and 15kV ESD protection to keep your connected peripherals safe. Super Fast Speeds: This USB hub is 3.2 Gen 1 compliant, ensuring super-fast 5Gbps data transfer speeds. It supports super speed, high speed and full speed which enables it to be compatible with USB 2.0 / 1.1. Superior Build Quality: Housed in a rugged steel chassis with built in mountable flanges, the 10-port hub is perfect for installations in offices, labs, warehouses, heavy machinery, automation equipment, and other industrial applications. Secure Connections: Screw locking ports help ensure reliable connections. Upstream: 1 USB port, Type B connector, Screw-lock type Downstream: 16 USB ports, Type A connectors, Screw-lock type Power Connector: 2-Pin Terminal Block Mounting Options: Wall, Surface, and DIN Rail Description Introduction: The CG-10U3AML is an USB 3.2 Gen 1 Hub that comply with the Universal Serial Bus (USB) Specifications Revision 3.2 Gen 1 and work up to 5Gbps. It provides 10 downstream facing ports with standard A-type USB3.2 screw-lock connectors. Each downstream port has a Transaction Translator (TT) for legacy USB devices. The CG-10U3AML provides a unique self-power mode to work with wide range (+7~24V) input DC power from its terminal blocks. It supports USB charging specifications Rev. 1.2 by turning its downstream ports from a Standard Downstream Port (SDP) into Charging Downstream Port (CDP) or Dedicated Charging Ports (DCP). It supports fast-charging for Android and Apple devices (up to 2.4A). Since the USB is the most popular external port for the devices to connect to PCs, the CG-10U3AML provides an ideal solution to expand your USB ports to accommodate most critical applications immediately and save your investment. Specifications: System For Systems with USB3.2 Gen 1, USB2.0, or USB1.1 Ports USB Ports Provides 10 USB downstream ports that manages up to 5Gbps: Compliant with USB Specifications 3.2 Gen 1 Provides 10 USB3.2 Gen 1 Downstream Facing Ports Supports BC v1.2: SDP, CDP and DCP Modes Supports Fast-Charging Feature for Android and Apple Devices (up to 2.4A) Supports 5Gbps, 480Mbps, 12Mbps and 1.5Mbps Speed Supports Multi Transaction Translators Supports Wide Range Input Self-power Mode from Terminal Blocks Supports +7~24V DC Wide Range Self-power Input Supports USB Screw-lock Cable Mechanism Supports 15KV ESD Protection for Each Port. Flexible Mounting Options: Wall and DIN Rail Mount USB Devices Supports keyboard, mouse, monitor, scanner, printer, PC Camera, Tablet, telephone, DVD drive, joystick, virtual reality helmet, modem, PBX and many more USB devices I/O Hardware Supports 10 external USB3.2 Type-A connectors and 1 USB3.2 Type-B Upstream connector. Supports a 2-pin Terminal Block Connector for external power input from AC adapter Environmental: Operating Temp.: 0 to 70C (32 to 158F) Storage Temp: -20 to 85C (-4 to 185F) Operating Humidity: 5 to 95% RH Form Factor 7.78(L)x2.18(W)x1.22(H) (197.755.531.0 mm) Package Contents: 10 Port USB 3.2 Gen 1 Hub USB-A to Screw Lock USB-B Cable 2-Pin Terminal Block DIN Rail Mounting Clips Screw Pack *Surface Mounting screws not included. Specifications Product Specifications Environmental Operating Temperature 0C to 70C (32F to 158F) Storage Temperature -20 to 75C (-4 to 167F) Humidity 5% ~ 95% (non-condensing) Performance ESD Protection 15KV Surge Protection for Each Port Max Data Transfer Rate 5Gbps Over Voltage Protection Y per buck Hardware Chipset GL 3523 Charging Protocols BC 1.2, Charging Downstream Port (CDP), Dedicated Charging Port (DCP) LED Indicators Power Product Information Warranty 1 year from date of purchase Power Input Voltage +7~24V DC Over Voltage Protection Y per buck Power Source 2-Pin Terminal Block, AC Adapter Not Included Idle Consumption 0.75mA @ 12V Terminal Power, 0.76mA @ 24V Terminal Power, 46.42mA Bus Power External Power Required No Software OS Support Win 11, Linux, Mac OSX, Win 10, Win 7, Win 8 What's in the Box Package Contents 2-Pin Terminal Block, DIN Rail Clip(s), Hub, Screw Pack, USB-A to Screw Lock USB-B Cable USB USB Type USB 3.2 Gen 1 Upstream USB Ports 1 Type-B Female USB Downstream USB Ports 10 Type-A Female USB Screw Lock Compatible Yes Mechanical Color Black Item Dimensions (L W H) 7.78 2.18 1.22 in. Item Weight 0.731 lbs. Mounting Style Surface / Wall Mount, Din-Rail Mount Ports 10 USB Ports Material of Construction Galvanized Steel Compliance Country of Origin Taiwan Certifications RoHS Other Data UPC 045079163126 Series FFS-UH (Front-Facing Series Hubs) Weight 1.20625 lbs Dimensions 9.583 6.605 2.448 in UPC: 045079163126
